5kW, 48V Off Grid Solar Inverter Price in India: Specifications & Compressions

5kW Off Grid Solar Inverter Summary

5kW Off Grid Solar Inverter Videos

5kW Off Grid Solar Inverter Price in India

5kW Off Grid Solar Inverter Price in India starts from ₹ 95,000. The lowest price of 5kW Off Grid Solar Inverter is ₹ 95,000 at Loom Solar on  .

5kW Off Grid Solar Inverter Full Specifications

General
Brand Loom Solar
Capacity / Model 5kW / FUSION H51
Price in India
 95,000
Rated Output Power 5000 W
Warranty 2
PV Input (DC)
Max. PV Power (W) 6000
Max. PV Array Open Cuircuit Voltage 145 VDC
MPPT Range at Operating Voltage 60 - 115 VDC
Number of MPPT 2
Grid-tie Operation
Grid Output (ac)
Nominal Output Voltage 220 - 240 VAC
Feed-in Grid Voltage Range 184 - 253 VAC (Settable)
Feed-in Grid Frequency Range 47.5 - 57.5 Hz
Nominal Output Current 21.7 A
Power Factor >0.99
Maximum Conversion Efficiency (DC/AC) 92.50%
Nominal Grid Freq. (Hz) MC4 IP68 Compatitble
Off-grid Operation (Hybrid Mode)
Grid Input
Acceptable Input Voltage Range 170-280 VAC Per Phase
Nominal Frequency 50 Hz
Maximum AC Input Current 40A
Battery Mode Output (AC)
Nominal Output Voltage 220-240 VAC
Output Waveform Pure SIne Wave
Battery & Charger
Nominal DC Voltage 48 VDC
Maximum Charging Current 180A
Interface
Parallel Function (optional) Yes
Communication (optional) USB or RS232

5kW Off Grid Solar Inverter Comparisons

5kW 3kW
Solar Cell (mm)
Maximum Power (W)
Maximum Voltage (V)
Maximum Current (A)
Efficiency (%)
Toughened Glass (mm)



Dimensions (L x W * H)



Weight (kg)
Frame (mm)
Number of diodes

5kW Off Grid Solar Inverter User Review & Ratings

5kW Off Grid Solar Inverter EMI / Loan Process

550w solar panel on emi

You can buy 550W solar panel for just pay ₹ 2,227 per month EMI for 12 months, and you need to pay ₹1,725 extra. You can calculate your monthly EMI here.

5kW, 1Phase Solar Inverter Installation Process

Step 1: Type of Roof
Step 2: Shadow Free Area
Step 3: Mounting Structure
Step 4: Placement (As per space no. of rows will decide)
Step 5: Structure Assembling
Step 6: Panels Mounting
